Industrial borescopes
Model Number:
Place of Origin:
Keywords:Industrial borescopes,Industrial borescopes manufacturers,Industrial borescopes sales,Industrial borescopes wholesale,Industrial borescopes price
Next Previous

Product Details

Industrial borescopes.


Industrial borescopes is a new NDT detector that integrated with optics, electronic technology, precision machinery and microphotography technology.

Industrial borescopes Camera Probe diameter:2.4mm,2.8mm,3.9mm,6.2mm non waterproof.6.4mm waterproof. 8.4mm.

Industrial borescopes Material:Stainless steel Stainless steel Titanium alloys.


Image sensor:5CMOS,5CMOS.3.5CMOS,4.5CMOS,4.5CMOS.

Illumination Highlight LED.

Industrial borescopes Probe's length:10mm.15mm.

Industrial borescopes Pixels:300,000,1,000,000.




Temperature sensing:Yes.

Insertion cable Length:1.5m,2m,2m/3.5m/6m.

Industrial borescopes Material:Stainless steel,Stainless steel Tungsten.

Articulation:part Bending angle90°(2 way). 90°(2 way).90°(360°).

Bending part operation Manual joystick. Probe interchangeability.

Controller LCD size:5 inches.

Material of the controller ABS.

Industrial borescopes Resolution:1200*720.


Industrial borescopes Brightness:600 CD/m2.

Industrial borescopes supply Battery:3.7V/6000MAH.

Industrial borescopes Working time:More than 4 hours.

Industrial borescopes Charging time:5 hours.

AC input:AC 100-240V 50/60Hz 0.35A.

AC output:5V 2A.

Brightness:adjustment Manual 5 levels.

Auxiliary light life 100,000 hours.

Lighting type:High brightness LED.

System memory.

Audio Built-in mic.

speaker Wifi video.

Photo/video:function Real time 5-level and 3 times.

magnification(Capture)Operation system Multitasking operating system menu drive.

and key operation:Real time 5-level and 3 times.

magnification(Video)Software update Factory will provide the latest procedure.

and this updating will be finished by the users Playback.

function Video:Playback/Pause,Input/output,Video output NTSC/PAL output,

Pictures:Real time 5-level and 3 times magnification,USB nterface.

operation Photo/Video delete Storage.

Output interface HDMI/AV.

Date/time setting.

Industrial borescopes Storage media:Micro SD(32G).

14 languages,such as Chinese,English.

Photo format:JPEG.

SD card format Operation.
